F&P Downpipe Lines #4377.2

F&P Downpipe Lines #4377.2

orCall +39 393 577 2205

Description



FOR SEAMED DOWNPIPES

OF ALUMINIUM, PREPAINTED MATERIALS, STAINLESS STEEL, TITANZINC, ZINC - .55mm to .80mm thick


STOP/START TYPE


Max.: 20m / minute



Layout dwg. in the Attach. at the bottom



COMPOSITION:



POWERED DECOILER


  • of allsteel construction with heavy duty bearings
  • 400mm max. coil width
  • 3 ton load capacity
  • Coil ID: 470-520mm
  • Mechanical mandrel drum closing/opening; hydraulic optional
  • 2.2kW drive motor
  • COIL CAR optional


ROLL FORMER


  • 13 station
  • 70mm shaft diameter
  • 800mm roll space
  • speed 0-20m / minute, variable
  • 18kW drive motor -- D.C. or, alt. A.C. (12kW) with inverter


ROLL TOOLING


  • 2 sets of rolls mounted "parallel" to each other for different pipe diameters on demand: for example 80mm + 100mm, or 87mm + 90mm, or 100mm + 120mm...
  • all rolls of tempered steel with partial grinding and complete with spacers; marked with: the station number, the progressive number, their position


STATIC HYDRAULIC POWER CUTOFF UNIT


  • with allsteel tool-holding bed, tooling for two pipe diameters ^
  • the cutting operation is by knife, with scrap
  • 2.5kW motor


HYDRAULIC ON-LINE AUTOMATIC BELLING UNIT for one pipe end*

(*on demand: for both ends -- but in this case, with operator intervention)


  • interchangeable tooling for two pipe diameters

_


PIPE SHRINK-WRAPPING EQUIPMENT for 3 to max. 6 pipes

-- including:

  • pipe accumulation table with sensors for parts-count and an air operated part separator
  • pipe pack preparation section > a belt conveyor with cut-stress resistant carpet and an air operated pipe head jogger
  • auto. shrink-wrapping machine with pipe entry belt conveyor and stopping blade
  • wrapped pipe pack exit section, with an air operated system to move pack to an accumulation area
  • an 'external' control panel to set the various parameters, including the number of pipes per-pack



GENERAL CONTROL PANEL.with: all pushbuttons for manual and, resp. automatic operation modes - "Schneider" Brand PLC - 'MODBUS TCP/IP' Communication Protocol - simple and intuitive HMI



ALL ELECTRICS, HYDRAULICS AND PNEUMATICS


SAFETY GUARDING TO 'CE'






In your requests for quotations, please specify:



a)  Type of process material/s

b)  Tensile strength min/max

c)  Yield strength min/max

d)  Material thickness min/max

e)  Diameter/s of pipes

f)  Pipe length min/max

g) Wanted "finish" of pipe ends



-

Specifications

ManufacturerF&P
ModelDownpipe Lines #4377.2
ConditionNew
