FIMI Rotary Shear CTL Line (Used) #3558

FIMI Brand Rotary Shear Cut To Length Line for: Cold Rolled, Galv., Pickled Steel, Stainless Steel, Aluminium... +/- "any materials" Coils: 300mm to 1500mm wide x .5mm to 3.0mm / max. 15ton Sheet Stacker: 6000mm 60m / min Very good condition (Dismantled, warehoused) -- Process materials - Tensile strength N/mm2 max. 500 - Yield strength N/mm2 max. 380 - Coil ID 508mm to 610mm ( "large expansion" mandrel drum with no spacers to add/remove) - Coil OD 700mm to 1650mm Products 350mm to 6300mm sheets Sheet stack specific load capacity: 1500kg/m Sheet stack height incl. pallet: max. 500mm -- - Line direction right to left - Line reference center - Material entry feed speed: 15m / min - Line footprint: ca. 9m x 50m incl. safety fencing - Floor pit for the sheet stacker: ca. 2m x 8m x 1m deep -- - Length tolerances: max ± 0, 25 mm (at constant line speed) for sheets up to 2000mm in length + for every extra meter: ± 0,10 mm are to be added ^ -- El. Power Supply Voltages - Three-phase 400 V 50 Hz - Auxiliary 220 V 50 Hz - Electrovalves 110 V Hydraulic power pack - Work pressure (nominal) 100 bar Pneumatics - Operating pressure (nominal) 6 bar Ambient temp. min 5 °C max. 40°C -- EQUIPMENT LIST B01) ENTRY COIL CAR - Coil elevator "under floor level” (pit), movable by hydraulic motor - “V” shape saddle, covered with anti-scratch material to support coil - Side Coil Storage for 2 coils B02) UNCOILER - Movable in resp. to central line axis, ± 100 mm - D.C. motor driven, 22.9kW - Pneumatic stand-by brake OVERHUNG MANDREL DRUM - Mandrel ø 508÷610 (large expansion), table width approx.: 1700mm SNUBBER ARM - Up / down motion by hydraulic cylinder - Hold-Down Roll rotation by hydraulic motor B03) COIL THREADING TABLE - Opening from top side - Table with fixed opening-tooth - Lifting / extension movements: by hydraulic cylinders B04) MATERIAL FEED PINCH ROLLS (2 Rolls) - lower roll rotation: by hydraulic motor - upper idle roll vertical movement: by hydraulic cylinders B05) Self-centering system for coil edge control (Edge Guide) B06) 6-HI LEVELER with intermediate rolls and back-ups (7 +7 Series) - Roll cassette: 17 work rolls, with diameter: 48mm - Upper leveling rolls: 8 - Lower leveling rolls: 9 - Rotation of work rolls by D.C. motor, 124.9kW - Stand-by pneumatic disk brake - Lower back-ups parabola adjustment by 7 hydraulic cylinders - Localized correction digital readout (visualized) - Penetration digital readout (visualized) B07) EXIT PINCH ROLLS for PVC Film Dispensers, DC motor driven B08) Tachometer-Wheel - to measure the sheet length B09) ROTARY SHEAR with blades clearance adjustment Complete with exit belt conveyor and scrap box (Scrap carriage with manual sideways extraction) DC motor, 143kW Production Speed: Length mm N° cuts max / minute 500 90 1000 50 1500 40 2000 30 2500 24 3000 20 4000 15 5000 12 6000 10 B10) CONVEYING SYSTEM to sheet stacker - Rotation of belts by DC motor B11) PNEUMATIC SHEET STACKER - 6000mm long with 2 racks (3.000+3.000) with sheet support system to prevent scrathes - with automatic pallet dispenser B11.1) STACKING PLATFORM - static, secured to foundation - useful length: 6000mm - platform lifting movement by jacks - powered chain-table, with rotation by AC motor - package off-load: along the line axis B11.2) CHAIN-TABLE - static, secured to foundation - chain rotation by AC VVVF motor B11.3) SIGNODE Automatic Bundle Strapping System for ¾” steel straps B11.4) EXIT CHAIN-TABLE - static, secured to foundation - chains rotation by AC VVVF motor - complete with Weighing Cells to reach a 5ton stack weight B12) HYDRAULICS & PNEUMATICS - Hydraulic central unit location: within 6m from main line axis - Oil-cooling forced air heat exchanger - Hydraulic electro-valves: of single-stand design, on board of each line part - On board pneumatic valves for each line part B13) ELECTRICS & ELECTRONICS - AC VVVF main motors - Motors and sensors onboard, for each line part - Ventilated, IP23 Electric cubicles (air conditioning not included) at max 6m from main line axis SAFETY FENCING and Photo-Electric Barriers
