Description



150.000ton / year



To produce 130mm x 130mm square steel billets


Feeding material for the EAF: 100% scrap




Equipment designed to European standards






EQUIPMENT LIST :



o   EAF

o   CCM

o   FUME-DEDUSTING SYSTEM

o   WATER TREATEMENT SYSTEM

o   AUXILIARIES





EAF ^


-      Nominal capacity: 40 t

-      Tapping capacity : 40 t

-      EAF type: Eccentric Bottom Tapping

-      Shell diameter: 4500mm

-      Electrode diameter: 450mm

-      Transformer nominal power: 30 MVA

-      Electro-hydraulic system for automatic regulation of electrode

-      Tap-to-tap time: about 45 minutes

-      Primary voltage: 45.000 V

-      Secondary voltage: 650 V

-      No. of taps:  25



CCM ^

·

-      Curve radius: 6m

-      Number of strands: 3

-      Average casting speed: 2.3m / minute

-      Cooling bed, hydraulic push type



AUXILIARIES ^



         Transfer Cars


-        Ladle transfer Car

-        Scrap basket Car



         Pre-Heaters & Dryers


-          Horizontal Dryer for ladle

-          Vertical pre-heaters for ladle

-          Vertical pre-heaters for Tundish

-          Vertical Dryer for Tondish



Ladle & basket


-          Basket for charge scrap

-          Ladle 40t



         EAF Accessories


-          Manipulator lance oxygen and carbon

-          Carbon injection system

-          PCC System for Melt Shop 200kt/h (Elbow and room calm)



         Melt Shop Crane


-          Casting Crane 120/40/10T

-          Scrap Crane 70T

-          Billet Crane 15T

-          Set of Grabs, Electro-hydraulic






-


Specifications

Manufacturer. . .
ModelBillet Melt Shop + Caster (Used) #4269
ConditionUsed
