F&P 2500mm x 1-10mm Alu. CTLL #4376

(For more details on this line please contact us, thank you)

Line max. speed 50m / minute

(max. 30m / minute recommended to reach laser cutting quality)

Max tension on uncoiler for thickness range 1÷10mm:

N 120000

Yielding value:.

N/mm²      ≥ 400

Process material:

all grades of Aluminium

Surface quality:

oiled or dry

Tensile strength at material thickness up to 10mm:

max  610 N/mm²

Yield strength at material thickness up to 10mm:

max 550 N/mm²

Elongation:

max 30%

Coil telescoping:

max. ±20mm .

Coils:

Width

800 ÷ 2500mm

Thickness

1 ÷ 10mm

Max weight

17 tons

Min outside diameter

1100mm

Max outside diameter

2200mm

Inside diameter

508- 620mm

Products:

Sheet dimensions

max width. x max length 2500mm x 15000(7500+7500)mm

min width. x min length 800mm x 1000mm

Max. shet stack weight (7500+7500 mm) / 2box

15000kg

Max sheet stack height including wooden joists or pallets

500mm

Max weight per-meter

2000kg

Stacking 1mm x 2500mm wide sheets on first box only

Length tolerance

at constant speed, up to a 2m length, £ ± 1mm

per each meter in addition, over a 2m length, £ ± 0,1mm

N.B. The above values applying to differences in length among sheets of a same cluster

Tolerance on sheet diagonals up to a 2m length £   ±  2mm

(for diagonal differences on edge-trimmed sheets)

Material with trimmed edges:

burr, with blades in initial sharpening conditions ≤ 4 %

Camber at 1m sheet length, no more than 2mm

Flatness: max 3 waves on 2500mm if the entry strip wave max 30mm

Sheet guaranteed for laser cutting - length 1000mm with wave height max 3 mm

Plasticity for laser cutting 75-80 %

-
