F&P Trapez. Sheet Lines i.g. (New) #5054

New Trapezoidal Sheet Lines STANDARD RANGE - Stop/Start Type (Flying Shear Option available) -- This range is for .45mm-1.00mm material thickness and for: - max. 50mm high sections - coils up to 1250mm wide Line speed up to 40m / min -- Typical Line Features: Decoiler for 6 / 8 / 10 & 15 t coil weight powered hydraulic expansion of mandrel ultrasonic sensor for loop control Coil Car for 6 / 8 / 10 & 15 t coil weight hydraulic lifting Roll Former width adjustable material entry guide number of Stations: 20-26, depending on profile geometry Roll Tooling in heat-treated toolsteel Static Post-Cut Shear eccentric with 2.2 kW motor Shaped Cutoff Blades Automatic Stacking Table - length: 6 / 8 / 10 / 12 m options Run-Out Conveyor - length: 6 / 8 / 10 / 12 m ^ Electrics (Siemens components) Hydraulics Safety Light Curtains
